SMT High Precision Vertical Dual-Station Laser Soldering Machine for PCB & FPC

Name: SMT High Precision Vertical DualStation Laser Soldering Machine for PCB amp FPC
Brand: YUSH
Price: 29000 USD

Certification : CE

Supply Ability : 1000

Payment Terms : L/C, D/A, D/P, T/T

Delivery Time : 20work days

Brand Name : YUSH

Price : USD 29000

Packaging Details : wooden case

Place of Origin : China,Guangdong

MOQ : 1

Contact Now

SMT High Precision Vertical Dual-Station Laser Soldering Machine for PCB & FPC

Advanced Laser Soldering Technology

This high-precision vertical dual-station laser soldering machine delivers exceptional performance for PCB and FPC applications with advanced temperature monitoring and non-contact soldering capabilities.

Key Advantages

Infrared temperature sensor monitors solder joint temperature in real-time, preventing component damage from excessive heat
Non-contact operation eliminates stress on workpieces
Quantified soldering data for easy analysis and process optimization
Fast laser heating rate enables high soldering speed
CCD vision positioning ensures exceptional accuracy
Five-light coaxial achromatic optical system expands soldering process capabilities
Unique PC-based software control system with user-friendly interface and comprehensive functionality

SMT High Precision Vertical Dual-Station Laser Soldering Machine for PCB & FPC

Technical Specifications

Power Supply	AC 220V ±10V
Equipment Power Consumption	1200W
Solder Material Specifications	Compatible with solder wire and solder paste
Operating Environment	25°C ±5°C
Positioning Method	CCD Vision Automatic Positioning
Laser Power	70W / 100W / 150W
Working Distance	100mm - 130mm (Optical Continuous Adjustable Technology)
Product Dimensions	1100 × 110 × 1850mm
Effective Travel Distance	300 × 300 × 150mm (Customizable)
Spot Type	Circular Spot / Special-shaped Spot (Optional)
Repeatability Accuracy	≤ 0.02mm
CCD Positioning Accuracy	≤ 0.03mm
Programming Method	Visual Programming, PC Operation
Temperature Control Method	Real-time Temperature Control

Precision Engineering

Designed for high-volume PCB and FPC production, this laser soldering machine combines precision positioning with advanced temperature control to deliver consistent, high-quality results.
